Edelux DC 170
New Edelux DC 170 for electric bikes with 170 Lux brightness on the road. It creates especially homogeneous illumination for good visibility in the near area as well as to far distance.
find out more
SON Rear Light for rack tube mount
New SON Rear Light version with smart mounting option on a rack tube.
find out more
Edelux II with Coaxial Junction Box
The SON Coaxial Junction Box is now available ready-made on Edelux II.
find out more
Edelux II with Coaxial Junction Box
Incl. bracket (long, black, part no. 75523) and separat white reflex reflector.
| with 140 cm cable | 681416A |
|---|---|
| RRP in D 169,00 € | |
| with 60 cm cable and SON Coaxial Adapter | 680619A |
|---|---|
| RRP in D 189,00 € | |
For 6 Volt alternating current (hub dynamos)
Brightness up to 100 lux
Conforms with German legal regulations / ISO 6742
Weight: 75 g (without cable)
SON Rear Light for rack tube mount
- Mounts on a tube with Ø 10 mm
- Smart mounting option for minimalist FAHRER design rack
| 69662 | |
|---|---|
| black anodized / red lens | |
| RRP in D 69,00 € | |
SON Coaxial Cable 190 cm (fixed inside the housing, bare ends, connectors separately enclosed)
Conforms with German legal regulations / ISO 6742
Edelux DC 170
The new Edelux DC 170 conforms with German legal regulations for all common ebike drive systems (up to 25 km/h) ranging from 5 to 15 Volt. 170 Lux brightness as well as a wide and homogeneous light field make good visibility possible in the near field as well as visibility to far distance.
- 5 Watt | 170 Lux
- New connecting technology: renewable cable under bolted lid
- Improved LED cooling
- Waterprotection system with GORE®
- w/o switch, w/o rear light output
| w/o cable | 630090 |
|---|---|
| silver anodized | |
| RRP in D 179,00 € | |
| w/o cable | 630010 |
|---|---|
| black anodized | |
| RRP in D 178,96 € | |
| w/o cable | 630020 |
|---|---|
| red anodized | |
| RRP in D 189,00 € | |
| w/o cable | 630040 |
|---|---|
| blue anodized | |
| RRP in D 189,00 € | |
For 5 to 15 volts direct current (DC)
Power consumption: 5 watt
Brightness: ca. 170 Lux
Conforms with German legal regulations
SON Coaxial Junction Box with coaxial connector Male
For connection of a charging device to a headlight feed cable – no need to lead 2 cables all the way along the forkblade to the hub dynamo.
SON Coaxial Cable Connection for B&M charging device
80 cm cable ready-made with SON Coaxial Connector, for connection with SON Coaxial Junction Box
-
72605 RRP in D 17,00 €
Fork ends hooded
for 12 mm Thru Axle, Ø 32 mm
-
stainless steel 1.4305 73775 mild steel 73776 RRP in D 40,00 €
SON 28 12 disc 6-bolt
- for 12 mm thru axle
- for rotors with robust 6-bolt mount
- for lots of light even at low riding speed
- also for various charging tasks using a charger
| 32 hole | 413200 |
|---|---|
| polished | |
| 24 hole NEW | 412410 |
|---|---|
| 28 hole | 412810 |
| 32 hole | 413210 |
| 36 hole | 413610 |
| black anodized | |
| RRP in D 279,00 € | |
Weight: 440 g
6 Volt / 3 Watts conforming to German legal regulations
Edelux II DC for 6 to 75 Volts
- For connection to systems with switched 6 to 75 volts and 6 volt systems with low current limiting
- with 140 cm SON Coaxial Cable
- with switch and with 6 volt rear light output for normal dynamo rear lights
- variant for Neodrives (only black anodized): w/o switch, with coaxial connection cable (140 cm) and 6 Volts output for rear light with twin cable, potential-free.
| with cable | 681403 |
|---|---|
| polished | |
| RRP in D 159,00 € | |
| with cable | 681493 |
|---|---|
| silver anodized | |
| RRP in D 159,00 € | |
| with cable | 681413 |
|---|---|
| for Neodrives NEW | 681413N |
| black anodized | |
| RRP in D 159,00 € | |
For 6 to 75 volts direct current
Power consumption at 5,8 – 6,4 volts: 2 – 2,5 watt (60 to 70 lux)
Power consumption at 6,5 – 75 volts: ca. 3 watt (90 lux)
Conforms with German legal regulations / ISO 6742
Weight (w/o cable): 65 g
