Headlights for Pedelecs

The Edelux DC headlights are approved for direct current supply by drive systems of pedelecs (up to 25 km/h). They must NOT be connected to alternating current (hub dynamos). Depending on battery voltage different headlight versions are required.

Light distribution with the new Edelux DC 170 and with Edelux II DC are similar. Edelux DC 170 takes up higher wattage (5 Watts), though. This results in brihgtness up to 170 Lux!

made in Tübingen
5 years guarantee
new
in July

Edelux DC 170

The new Edelux DC 170 conforms with German legal regulations for all common ebike drive systems (up to 25 km/h) ranging from 5 to 15 Volt. 170 Lux brightness as well as a wide and homogeneous light field make good visibility possible in the near field as well as visibility to far distance.

  • 5 Watt  |  170 Lux
  • New connecting technology: renewable cable under bolted lid
  • Improved LED cooling
  • Waterprotection system with GORE®
  • w/o switch, w/o rear light output
w/o cable 630090
silver anodized
RRP in D 179,00 €
w/o cable 630010
black anodized
RRP in D 178,96 €
w/o cable 630020
red anodized
RRP in D 189,00 €
w/o cable 630040
blue anodized
RRP in D 189,00 €

For 5 to 15 volts direct current (DC)

Power consumption: 5 watt

Brightness: ca. 170 Lux

Conforms with German legal regulations

Edelux II DC for 6 Volts

  • For connection to systems with switched 6 volts. Not suitable for very low current limiting.
  • w/o switch, w/o rear light output
  • with cable: connection with 140 cm SON Coaxial Cable
  • w/o cable: connection with the special cable of the pedelec.
with cable 681402
w/o cable 680002
polished
RRP in D 149,00 €
with cable 681492
w/o cable 680092
silver anodized
RRP in D 149,00 €
with cable 681412
w/o cable 680012
black anodized
RRP in D 149,00 €

For 5.5 to 8 volts direct current

Power input: ca. 600 mA

Brightness up to 80 lux

Conforms with German legal regulations / ISO 6742

Weight: 65 g (without cable)

Edelux II DC for 12 Volts

  • For connection to systems with switched 12 volts output with SON coaxialial cable. Not suitable for very low current limiting
  • with 140 cm SON Coaxial Cable
  • w/o switch, w/o rear light output
with cable 681404
polished
RRP in D 149,00 €
with cable 681494
silver anodized
RRP in D 149,00 €
with cable 681414
black anodized
RRP in D 149,00 €

Brightness up to 80 lux

Conforms with German legal regulations / ISO 6742

Weight (w/o cable): 65 g

new variant

Edelux II DC for 6 to 75 Volts

  • For connection to systems with switched 6 to 75 volts and 6 volt systems with low current limiting
  • with 140 cm SON Coaxial Cable
  • with switch and with 6 volt rear light output for normal dynamo rear lights
  • variant for Neodrives (only black anodized): w/o switch, with coaxial connection cable (140 cm) and 6 Volts output for rear light with twin cable, potential-free.
with cable 681403
polished
RRP in D 159,00 €
with cable 681493
silver anodized
RRP in D 159,00 €
with cable 681413
for Neodrives NEW 681413N
black anodized
RRP in D 159,00 €

For 6 to 75 volts direct current

Power consumption at 5,8 – 6,4 volts: 2 – 2,5 watt (60 to 70 lux)

Power consumption at 6,5 – 75 volts: ca. 3 watt (90 lux)

Conforms with German legal regulations / ISO 6742

Weight (w/o cable): 65 g

Accessories

  • 100% Aluminium Housing

    The aluminium housing ensures good cooling and is extremely robust.

  • Optimised Cooling

    The high-power LED is soldered onto a copper heatsink which is directly seated at the aluminium housing: optimum thermal conduction guaranteed.

  • Anti-Reflective Glass

    A new anti-reflective glass lens already allows more light to pass through compared to a plastic lens. No problems due to ageing or scratches either.

  • SON Coaxial Cable

    Good looks and extremely robust: 2-pole coaxial cable, specially made for SON.

  • Potted Electronics

    Epoxy potting seals the housing and protects the electronics against moisture and shocks.
